Close Body Laser Cutting Machine
Fully enclosed cutting cell for maximum safety and a clean shop floor.
Laser Cutting MachineOverview
Close Body Laser Cutting Machine
The Close Body Laser Cutting Machine is a fully enclosed cutting cell that contains fumes, sparks and laser light for a safer, cleaner working environment. Ideal for facilities that prioritise operator safety and workplace compliance without compromising cutting performance.
Key Features
- Fully enclosed protective cabin
- Contains fumes, sparks and laser radiation
- Precision cutting with high positioning accuracy
- Integrated fume-extraction ready design
- Compact footprint for busy shop floors
Technical Specifications
Engineered to precise tolerances.
| Model | F3015 | F4015 | F6020 | F6025 |
|---|---|---|---|---|
| Working Area | 3000×1500 mm | 4000×1500 mm | 4000×2000 mm | 6000×2500 mm |
| Positioning Accuracy | ±0.03 mm | ±0.03 mm | ±0.03 mm | ±0.03 mm |
| Repositioning Accuracy | ±0.02 mm | ±0.02 mm | ±0.02 mm | ±0.02 mm |
| Max Movement Speed | 140 m/min | 140 m/min | 140 m/min | 140 m/min |
| Laser Power | 1000-6000 W | 1000-6000 W | 1000-6000 W | 1000-6000 W |
| Working Table | Blade Table | Blade Table | Blade Table | Blade Table |
| Max Acceleration | 1.4 G | 1.4 G | 1.4 G | 1.4 G |
* Specifications are indicative and may vary by configuration. Contact us for a detailed technical datasheet.
Related Machines
All Products
Laser CuttingSingle Pallet Fiber Laser Cutting Machine
Precision-driven fiber cutting for stainless, mild steel, aluminium, brass & copper.
View Details
Laser CuttingDouble Pallet Fiber Laser Cutting Machine
Exchange-table cutting that loads and unloads while the laser keeps working.
View Details
Laser CuttingTube / Pipe Laser Cutting Machine
